Sako TNS-40 KVA Three Phase AVR

  • Input
    • Three phase technology
    • Voltage is AC 280V-430V
    • The frequency is 50/ 60Hz
  • Output
    • Voltage is 380V +/-3 percent
    • The capacity is 36kW
    • The power is 80% when the input voltage is 380V
  • Comes with a servo motor control
  • Higher Voltage Protection
    • The protection will work when the output voltage is 246+/-4V
  • Lower Voltage Protection
    • The protection will work when the output voltage is 186+/-4V
  • Other Protections
    • Overload protection
    • Overheat protection
    • Natural cooling system
    • Delay up to 3-7 sec or 3-7 min selectable
    • Manual switching bypass function
  • An efficiency of more than 95%
  • The acoustic noise exposure is ≤50dB
  • Operating temperature range from -5 to 60°C
  • Operating humidity ranges from 20 to 90%
